RAY-311 Portable High Frequency Dental X-Ray Unit Square Type Xray Imaging System
.jpg "RAY-311 Portable High Frequency Dental X-Ray Unit Square Type Xray Imaging System")
Features:
Compatible with digital sensors, X-ray film, and image plate scanners.
Handheld design for portable use.
Compact and lightweight; radiation leakage measured below 20μGy/h.
Designed for image capture and storage in a space-saving format.
Uses frequency-conversion and DC power input.
Components are integrated on a central circuit board; the tube assembly is vacuum-insulated and enclosed for protection.
Preset exposure durations for adult and pediatric imaging.
A full charge provides about 400 exposures; actual results vary with usage.
Technical Specifications:
Tube Voltage: 60 kV / 70 kV
Tube Current: 2.0 (1.0, 1.5, 2.5) mA
Rated Power: 100–300 VA
Focus Size: 0.8 × 0.8 mm / (Optional: 0.4 × 0.4 mm)
Battery Voltage / Capacity: 14.8V, 1600mAh
Charger Input: AC 110–240V, 50/60Hz
Charger Output: DC 16.8V
Exposure Time Range: 0.1–2.0 s
Distance from Collimator Tube to Skin: 130 mm
Operating Frequency: 30 kHz
Ambient Temperature Range: 5°C–40°C
Relative Humidity: ≤75% RH
Net Weight: 1.7 kg
Gross Weight: 3.5 kg
Dimensions: 150 × 145 × 140 mm
.jpg "RAY-311 Portable High Frequency Dental X-Ray Unit Square Type Xray Imaging System")
.jpg "RAY-311 Portable High Frequency Dental X-Ray Unit Square Type Xray Imaging System")
.jpg "RAY-311 Portable High Frequency Dental X-Ray Unit Square Type Xray Imaging System")
.jpg "RAY-311 Portable High Frequency Dental X-Ray Unit Square Type Xray Imaging System")
.jpg "RAY-311 Portable High Frequency Dental X-Ray Unit Square Type Xray Imaging System")
.jpg "RAY-311 Portable High Frequency Dental X-Ray Unit Square Type Xray Imaging System")
